MES9000

MES9000 shop floor terminals
User-friendly industrial PCs for
manual workstations

The versatile MES Shopfloor Terminals from the 9000 series are ADS-TEC Industrial IT's answer to the industry's calls for paperless manufacturing. The powerful terminals can be quickly integrated into existing production landscapes. Manufacturing employees benefit in particular from the large and intuitive multi-touch display: Here they can manually record operating data or control manufacturing processes directly at their manual workstations - without any paperwork.

MES9000

Enhanced data security

The large multi-touch display of the MES9000 terminals facilitates the digital capture of operational data, eliminating the risk of data loss or degradation

MES9000

Improved data quality

Operational data digitally captured on the MES9000 can be enriched with manually captured information and is then available in real time for OEE and CIP calculations

MES9000

Enhanced productivity

In place of confusing production documentation on paper, employees can call up required information digitally via the terminals

MES9000

Increased reliability

Scanning barcodes or logging the user in and out via RFID avoids potential errors that can occur with paper shop floor data collection

IP65 protection all round
(optional)

Multi-touch display
in Full HD

Integrated power supply unit
24V DC or 230V AC

User identification
via RFID

MES9000
The versatile and powerful MES terminal for optimal operation and efficient data acquisition

ultra strong
performance
MES9000

Intel® Gen. 8 (Whiskey Lake)

MES9000

Windows 10 IoT Enterprise

MES9000

Memory up to 32 GB DDR4 RAM

MES9000

SSD M.2 mass storage

Trend-setting technology for numerous tasks in production

In terms of performance, design and connectivity, MES9000 industrial terminals offer everything that is required in modern manufacturing.

01

Convenient
operation

Benefit from the latest in operation technology: The MES terminals have a capacitive multi-touch display with full HD resolution, which enables convenient multi-finger operation - even with gloves.

MES9000
MES9000

Multi-touch screen

MES9000

Multi-touch screen

MES9000

Full HD Screen

02

Versatile
connectivity

Use the versatile interfaces of the MES terminals from the 9000 series. This makes it easy to connect different peripheral devices and wireless networks.

MES9000
MES9000

Integrated WLAN antennas

MES9000

HDBaseT

MES9000

DisplayPort++

MES9000

RFID

MES9000

Front USB port

MES9000

Bluetooth

03

Simple
assembly

Benefit from the simple and quick assembly: The MES9000 mounting concept enables the flexible installation of the unit on the support arm, table base or wall - to suit the customer's individual installation situation. Other accessory components, such as a keyboard and scanner holder, can be attached to the top and bottom of the terminals via threaded sockets.

MES9000
04

Innovative
industrial design

Rely on the innovative industrial design of the MES9000 Series: Developed and manufactured in Germany, the HMIs are characterised by their high long-term availability and durability. Featuring all-round IP65 protection, the terminals can be easily cleaned with water. To ensure the appropriate power supply, the MES9000 are equipped with an integrated 24V DC or 230V AC power supply unit.

MES9000

Technology with long-term availability

MES9000

High durability

MES9000

Fan-less design

MES9000

Shock-resistant according to IK08

MES9000

IP65 front panel (all-round protection optional)

MES9000

230V AC or 24V DC power supply

MES9000.
One series.
For all use cases.

MES9000

MES9000 series

Terminal PCs - MES9000

  • Three screen sizes, Full HD widescreen
    (15.6“, 18.5“, 23.8“)
  • Intel® Generation 8 CPUs (Whiskey Lake)
    Intel® Celeron® 4305UE 2.0 GHz Dual-Core
    Intel® Core™ i5-8365UE 1.6 GHz Quad-Core
  • SSD M.2 with up to 2x 256 GB
    (optional RAID system)
  • RAM DDR4 up to 32 GB
  • 4 x USB 3.2 Gen. 2x1 (10 Gbit/s)
  • 3 x Ethernet (10/100/1000 Mbit/s)
  • 1 x DisplayPort++ (1.2)
  • 2 digital I/Os at 24V DC
  • Smartcard reader for secure Industrial IoT
  • 230V AC / 24V DC
  • VESA mount
  • All-round IP65-protected
  • Wireless connection
  • Glove-operated

Custom adaptations?

OEM versions with regard to design, hardware, and software are no problem thanks to our in-house development capacity. Talk to us.
